AC Board Classic - 200A Single Inverter
Electrical switchboard details
Range: Classic (simplified functionality without compromising on performance or quality, just like our AC Board Pro Range)
This AC Board is a commercial solar distribution board suitable for most 3-phase commercial inverter brands.
This distribution board offers simplified functionality without compromising on performance or quality, just like our AC Board Pro range. Designed for commercial solar systems, it supports up to 110kW of inverter outputs
These Commercial Solar distribution boards accommodate all of the electrical hardware required to install three-phase commercial solar systems. It’s considered the fastest and easiest way to install commercial solar systems by many solar installers around Australia and New Zealand.
It comes fully labeled with additional labels for main switchboard
Grid protection relay (GPR) settings pre-configured to meet Australian Standards and utility requirements
We have SolarEdge commercial inverters, SMA commercial inverters (Sunny Tripower X 15kW, 20 kW and 25kW) and Sungrow commercial inverters. Contact us for inverter compatibility.
Key features and Benefits of AC Board Classic 100A Single Inverter
Ideal for commercial solar systems with a single inverter output of up to 110kW.
Compatible with any inverter brand.
Same high quality and trusted components such as Rittal enclosures and ABB/Siemens Switchgear.
Fully labeled with additional labels for the main switchboard.
Grid protection relay (GPR) settings pre-configured to meet Australian and New Zealand Standards and utility requirements.
Designed and certified by Registered Professional Engineers.
Save valuable time on site by eliminating wiring problems.
Uniform looks across all installs.
Standard designs & custom solutions available.
Manufactured in-house by AC Solar Warehouse, cutting out unnecessary steps in the supply chain, we ensure that you receive high-quality products at the best possible prices.
Some optional extras you might want to include
For little more than the cost of the components themselves, this solar switchboard saves valuable time on site, eliminates wiring problems and speeds up commissioning. If you still want to customize it more, here are some features that you may want to add:
Swap ABB Network Protection Relay for ComApp MainsPro (+$50)
Install test links for injection testing (+$100)
Install Generation Signalling Device (Queensland only) (+$100)
Install 3P+N AC surge diversion (+$250)
Mechanical specifications
Enclosure material: Powder coated mild metal
Enclosure dimensions: 600W x 800H x 250D (mm)
IP rating: IP 66
Weight: 48kg
Cable entries: Gland plate top + bottom
Labels: Pre-labelled to meet AS/NZS 4777.1:2016 & AS/NZS 5033:2021 with additional labels for main board.
Color: Grey (RAL7035)
Operating temperature: -25°C to +40°C Ambient
